1801551 - 12-24V LED Work Light with Flood Beam Pattern & Panel Mount
Oval LED Work Light - Model 7251 XD
7" x 6" Oval LED Work Lamps with Panel Mount
Applications
Oval LED Work Light - Model 7251 XD
7" x 6" Oval LED Work Lamps with Panel Mount
Model 7251 XD is a high output LED work light, made with a polycarbonate housing. This housing provides a lightweight, corrosion-resistant body, making these industrial work lights ideal for construction, mining and industrial equipment.
- Impressive LED light output - one of our brightest in the XD Series!
- Lightweight and corrosion-resistant polycarbonate housing
- Model 7251 XD comes with a panel mount
- Available in a pedestal mount configuration as the Model 7250 XD
Applications
- Agriculture
- Construction
- Industrial
- Mining
- Railroad
- Specialty Vehicles
- Truck & Bus
- UPC:
- 799475637094
- Part Number:
- 1801551
- Model:
- 7251 XD
- Shape:
- Oval
- Outer Lens Material:
- Polycarbonate
- Outer Lens Color:
- Clear
- Housing Material:
- Polycarbonate
- Housing Color:
- Black
- Min Operating Temp (F):
- -40
- Max Operating Temp (F):
- 65
- Connector or Wiring:
- Deutsch DT04-2P
- Mating Connector:
- Deutsch DT06-2S
- Raw Lumen Output:
- 3150
- Effective Lumen Output:
- 1400
- Input Voltage:
- 12-24
- Operating Voltage:
- 10-32
- Current Draw 1:
- 1.6
- NMFC:
- 17870
- NMFC Sub Code:
- 8
- HS Tariff:
- 8512.2
- Country of Origin:
- US
- Wire Color 1:
- Black
- Wire Function 1:
- Ground
- Wire Color 2:
- Red
- Wire Function 2:
- Power
- Technology:
- L
- Product Height (mm):
- 170.18
- Product Width (mm):
- 152.4
- Product Depth (mm):
- 68.58
- Product Weight (lbs):
- 0.8
