Cross References:
FJ5994081216S
- UPC:
- 815628021098
- Part Number:
- FJ5994-08-1216S
- Angle shape:
- 90 Degree
- Compatible hose ID IN:
- 1.000
- Compatible hose ID MM:
- 25.400
- Compatible hoses:
- GH134
- Compatible tube OD IN:
- 0.75
- Compatible tube OD MM:
- 19.050
- Construction Style:
- Reusable
- End size 1:
- -14
- End type 1:
- Female ORFS swivel
- Hex size 1 IN:
- 1.380
- Hex size 1 MM:
- 35.100
- Hex size 2 IN:
- 1.250
- Hex size 2 MM:
- 31.800
- Hose cut off factor IN:
- 1.780
- Hose cut off factor MM:
- 45.212
- Hose size:
- -16
- Inside diameter IN:
- 0.650
- Inside diameter MM:
- 16.510
- Product material:
- Carbon steel
- Tube OD 1 IN:
- 0.750
- Tube OD 1 MM:
- 19.050
- A dimension IN:
- 3.457
- A dimension MM:
- 87.800
- Thread size 1:
- 1 3/16-12 UN
- End connection torque:
- 63-75 lb-ft(85-102 Nm)
- Finish plating:
- Dura-Kote
- Drop dimension IN:
- 2.000
- Drop dimension MM:
- 48.00
- Compliances:
- SAE J2064 Type E, Class 1
