Cross References:
FJ5994020808S
- UPC:
- 678146014511
- Part Number:
- FJ5994-02-0808S
- Angle shape:
- 90 Degree
- Compatible hose ID IN:
- 0.500
- Compatible hose ID MM:
- 12.700
- Compatible hoses:
- GH134
- Compatible tube OD IN:
- 0.50
- Compatible tube OD MM:
- 12.700
- Construction Style:
- Reusable
- End size 1:
- -8
- End type 1:
- Female ORFS swivel
- Hex size 1 IN:
- 0.940
- Hex size 1 MM:
- 23.900
- Hex size 2 IN:
- 0.630
- Hex size 2 MM:
- 16.000
- Hose cut off factor IN:
- 1.200
- Hose cut off factor MM:
- 30.480
- Hose size:
- -8
- Inside diameter IN:
- 0.320
- Inside diameter MM:
- 8.128
- Product material:
- Carbon steel
- Tube OD 1 IN:
- 0.500
- Tube OD 1 MM:
- 12.700
- A dimension IN:
- 2.740
- A dimension MM:
- 69.596
- Thread size 1:
- 13/16-16 UN
- End connection torque:
- 35-46 lb-ft(47-62 Nm)
- Finish plating:
- Dura-Kote
- Drop dimension IN:
- 1.000
- Drop dimension MM:
- 29.00
- Compliances:
- SAE J2064 Type E, Class 1
