Cross References:
20Z-697, 20Z697
- UPC:
- 678146180599
- Part Number:
- 1AA20FJA20
- Series:
- 1A/Z Series
- Angle shape:
- 45 Degree
- Compatible hose ID IN:
- 1.250
- Compatible hose ID MM:
- 31.800
- Construction Style:
- Crimp
- End size 1:
- -20
- End type 1:
- Female 37 degree swivel
- Hose cut off factor IN:
- 2.710
- Hose cut off factor MM:
- 68.900
- Hose size:
- -20
- Inside diameter IN:
- 1.050
- Inside diameter MM:
- 26.600
- Product material:
- Carbon steel
- A dimension IN:
- 4.270
- A dimension MM:
- 108.400
- Thread size 1:
- 1 5/8-12 UN
- End connection torque:
- 127-133 lb-ft(173-182 Nm)
- Product length in:
- 6.080
- Finish plating:
- Dura-Kote
- Product height in:
- 4.060
- Product height mm:
- 103.124
- Product length mm:
- 154.432
- Product width in:
- 2.410
- Product width mm:
- 61.214
- Drop dimension IN:
- 1.220
- Drop dimension MM:
- 31.0
