Cross References:
12Z-696-BG, 12Z696BG, 12Z-696, 12Z696
- UPC:
- 678146125972
- Part Number:
- 1AA16FJA12
- Series:
- 1A/Z Series
- Angle shape:
- 45 Degree
- Compatible hose ID IN:
- 0.750
- Compatible hose ID MM:
- 19.000
- Construction Style:
- Crimp
- End size 1:
- -16
- End type 1:
- Female 37 degree swivel
- Hex size 1 IN:
- 1.496
- Hex size 1 MM:
- 38.000
- Hex size 2 IN:
- 0.000
- Hose cut off factor IN:
- 2.370
- Hose cut off factor MM:
- 60.200
- Hose size:
- -12
- Inside diameter IN:
- 0.610
- Inside diameter MM:
- 15.500
- Product material:
- Carbon steel
- A dimension IN:
- 3.430
- A dimension MM:
- 87.000
- Thread size 1:
- 1 5/16-12 UN
- End connection torque:
- 108-113 lb-ft(148-154 Nm)
- Product length in:
- 4.880
- Finish plating:
- Zinc plating
- Product height in:
- 3.190
- Product height mm:
- 81.026
- Product length mm:
- 12.395
- Product width in:
- 1.560
- Product width mm:
- 39.624
- Drop dimension IN:
- 1.060
- Drop dimension MM:
- 27.0
