Cross References:
1905166S
- UPC:
- 678146123053
- Part Number:
- 190516-6S
- Angle shape:
- 90 Degree
- Compatible hose ID IN:
- 0.380
- Compatible hose ID MM:
- 9.500
- Construction Style:
- Reusable
- End size 1:
- -6
- End type 1:
- Female 37 degree swivel
- Hose cut off factor IN:
- 0.830
- Hose cut off factor MM:
- 21.082
- Hose size:
- -6
- Inside diameter IN:
- 0.240
- Inside diameter MM:
- 6.096
- Product material:
- Carbon steel
- A dimension IN:
- 1.695
- A dimension MM:
- 43.053
- Thread size 1:
- 9/16-18 UNF
- End connection torque:
- 18-20 lb-ft(24-27 Nm)
- Product length in:
- 2.040
- Finish plating:
- Zinc plating
- Product height in:
- 1.610
- Product height mm:
- 40.894
- Product length mm:
- 51.816
- Product width in:
- 0.730
- Product width mm:
- 18.542
- Drop dimension IN:
- 0.851
- Drop dimension MM:
- 21.61
