Cross References:
1902968S
- UPC:
- 678146044358
- Part Number:
- 190296-8S
- Series:
- 100R5 Reusable
- Angle shape:
- 90 Degree
- Compatible hose ID IN:
- 0.500
- Compatible hose ID MM:
- 12.700
- Construction Style:
- Reusable
- End size 1:
- -8
- End type 1:
- Female 37 degree swivel
- Hex size 2 MM:
- 15.000
- Hose cut off factor IN:
- 1.610
- Hose cut off factor MM:
- 40.894
- Hose size:
- -8
- Inside diameter IN:
- 0.360
- Inside diameter MM:
- 9.144
- Product material:
- Carbon steel
- A dimension IN:
- 2.760
- A dimension MM:
- 70.100
- Thread size 1:
- 3/4-16 UNF
- End connection torque:
- 38-42 lb-ft(52-58 Nm)
- Product length in:
- 3.190
- Finish plating:
- Dura-Kote
- Product height in:
- 2.050
- Product height mm:
- 52.070
- Product length mm:
- 81.026
- Product width in:
- 0.938
- Product width mm:
- 23.813
- Drop dimension IN:
- 1.090
- Drop dimension MM:
- 27.69
- Reusable socket hex IN:
- 0.938
- Reusable socket hex MM:
- 23.000
