- Part Number:
- WAL063888
- Angle shape:
- Elbow 90 degree
- End size 1:
- 8S
- End type 1:
- 24 deg. DKO swivel heavy duty
- Hex size 1 MM:
- 14.000
- Hex size 2 MM:
- 19.000
- Product material:
- Carbon steel
- Thread size 1:
- M16x1.5
- End type 2:
- 24 deg. tube port heavy duty
- Item type:
- Adjustable connector
- Finish plating:
- Guardian Seal
- End size 25:
- 8S
- Seal material:
- Nitrile (NBR)
- Tube outside diameter 1 MM:
- 8.0
- Tube outside diameter 2 MM:
- 8.0
- Thread size 27:
- M16x1.5
- Working pressure bar:
- 800
- Working temperature max C:
- 400
- Working temperature min C:
- -60
- Complete connector:
- No
- Product serial name:
- EWSD
- Model Code 1:
- EWSD 8 S A4GS
-
TECH HELP LIVE TECH HELP AVAILABLE
-
LIVE INVENTORY WHAT YOU SEE IS WHAT WE HAVE
-
SAME DAY SHIPPING ORDER BY 4PM CDT MONDAY - FRIDAY
-
FAST, FREE SHIPPING on ORDERS OVER $199*
Aeroquip Walpro Adjustable Connector 90 degree Elbow 8S DKO Swivel Heavy Duty Guardian Seal Carbon Steel | WAL063888
$14.11
- SKU:
- WAL063888
- Weight:
- 18.29 LBS
Product Info
Current Stock:
