0549841 - 12-24V LED Work Light with Trapezoid Pattern
LED Work Light - Model 4415
3.5" Round LED Work Lights
Applications
LED Work Light - Model 4415
3.5" Round LED Work Lights
Overview
Our Model 4415 is a compact, powerhouse LED work light! Designed with a lower profile, lighter weight, and triple output for a convenient, bright-white work light. It is also available with an integrated camera system and 7" split-screen monitor that provides driver enhanced visual awareness on the sides and rear of the truck.
Features
- Die-cast aluminum housing & impact-resistant polycarbonate lens provide rugged durability
- Pedestal mount provides an easy install
- Available in Trapezoid & Spot beam patterns
- Trapezoid beam pattern provides a generous amount of light
- Side View Mirror Kit includes a pre-assembled shroud blocking spotlight from the driver's eyes, providing maximum visibility rearward
Looking for AC Power?
Use our Model 6404 35W AC/DC Converter.
Applications
- Agriculture
- Automotive
- Construction
- Industrial
- Material Handling
- Mining
- Motorcycle
- Off-Road 4x4
- Powersports
- Railroad
- Specialty Vehicles
- Truck & Bus
- UPC:
- 799475635977
- Part Number:
- 0549841
- Model:
- 4415
- Shape:
- Round
- Outer Lens Material:
- Polycarbonate
- Outer Lens Color:
- Clear
- Housing Material:
- Die-Cast Aluminum
- Housing Color:
- Black
- Min Operating Temp (F):
- -40
- Max Operating Temp (F):
- 85
- Connector or Wiring:
- Packard# 12084167
- Mating Connector:
- Packard#12059183
- Raw Lumen Output:
- 2450
- Effective Lumen Output:
- 1350
- Input Voltage:
- 12-24
- Operating Voltage:
- 10-32
- Current Draw 1:
- 2.2
- NMFC:
- 17870
- NMFC Sub Code:
- 8
- HS Tariff:
- 8512.2
- Country of Origin:
- US
- Wire Color 1:
- Red
- Wire Function 1:
- Positive
- Wire Color 2:
- Black
- Wire Function 2:
- Negative
- Technology:
- L
- Product Height (mm):
- 85.09
- Product Width (mm):
- 125.48
- Product Depth (mm):
- 56.9
- Product Weight (lbs):
- 1.4
