0550931 - 12-24 DOT/ECE LED RHT High & Low Beam Headlight with FP & Panel Mount
4x6 LED Headlights - Model 8820
4" x 6" LED Headlights
Applications
4x6 LED Headlights - Model 8820
4" x 6" LED Headlights
Designed for use in military and commercial trucks, the Model 8820 LED headlight offers heavy-duty construction and a redesigned, deeper housing built to stand up to harsh environmental conditions. New front position functionality, robust LEDs, and proprietary optics provide bright, white light for delivering superior visibility both on and off-road.
Constructed with tough die-cast aluminum housing, hard-coated polycarbonate lens, and solid-state LEDs resisting shock and vibration, the Model 8820 is built tough for a variety of heavy-duty applications.
- 4? x 6? LED high & low beam headlight
- DOT & ECE-compliant
- Available in both panel mount and the 3-point mount
Applications
- Industrial
- Specialty Vehicles
- Construction
- UPC:
- 708315994617
- Part Number:
- 0550931
- Model:
- 8820
- Shape:
- Rectangular
- Outer Lens Material:
- Polycarbonate
- Outer Lens Color:
- Clear
- Housing Material:
- Aluminum
- Housing Color:
- Black
- Connector or Wiring:
- 12" Flying Leads
- Raw Lumen Output:
- 2,100 (High Beam) | 1,850 (Low Beam)
- Effective Lumen Output:
- 755 (High Beam) | 645 (Low Beam)
- Input Voltage:
- 12-24
- Operating Voltage:
- 10-30
- Current Draw 1:
- 1.11
- NMFC:
- 17870
- NMFC Sub Code:
- 8
- HS Tariff:
- 8512.20.20.00
- Country of Origin:
- US
- Wire Color 1:
- Black
- Wire Function 1:
- Ground
- Wire Color 2:
- White
- Wire Function 2:
- High Beam
- Wire Color 3:
- Yellow
- Wire Function 3:
- Low Beam
- Wire Color 4:
- Red
- Wire Function 4:
- Front Position
- Technology:
- L
- Product Height (mm):
- 168.66
- Product Width (mm):
- 129.79
- Product Depth (mm):
- 87.38
- Product Weight (lbs):
- 2.5
