Grote 55162 4" Round LED Stop Tail Turn Light with Integrated Backup
FEATURES & BENEFITS ?Innovative patented design combines all Stop Tail Turn and Back-up functions into one industry standard size lamp. ?A new robust design for consistent compliance utilizing dedicated LEDs for Stop and Tail ?Provides high level electrical protection for: reverse voltage, over voltage, electrical transients, and overheating ?Designed to meet electrical specifications of all major Class 8 truck manufacturers ?Standard 4-Pin Hard Shell connector TECHNICAL SPECIFICATIONS Material: Lens: Red/Clear Polycarbonate Housing: Black Polycarbonate/ABS Blend FMVSS: I, S, T, R2 Voltage Amp: 12 Volt Other: Assembly : Laser Weld
- UPC:
- 89373155845
- Part Number:
- 55162
- Material:
- Polycarbonate Lens, PC/ABS Housing
- Color:
- Red, Clear
- Lens Color:
- Red/Clear
- Housing Color:
- Black
- Voltage:
- 12V
- Amperage:
- .08A-.31A
- Mounting Type:
- Grommet, Bracket
- Connection Type:
- Hardshell
- Size:
- 4"
- Regulations:
- FMVSS 108
- Functions:
- I, S, T, R(2)
- VMRS:
- 034-002-059
- Diameter:
- 4"
- Product Type:
- Stop Tail Turn
- Shape:
- Round
- Warranty Details:
- 10 Years
- Country of origin (CO):
- US
