Cross References:
H43012
- UPC:
- 678146081681
- Part Number:
- GH493-12
- Series:
- GH493 Series
- Application:
- Construction industry
- Color:
- Black
- Product height in:
- 0.750
- Product height mm:
- 19.000
- Product width in:
- 0.750
- Product width mm:
- 19.000
- Compliances:
- EN856 Type R12
- Conductivity:
- Conductive
- Construction:
- 4 Wire Spiral
- Cover material:
- Styrene Butadiene Rubber (SBR)
- Reinforcement material:
- Brass plated steel wire
- Tube material:
- Nitrile (NBR)
- Certifications:
- USCG
- Abrasion resistance:
- Premium
- Bend radius min (inch):
- 4.720
- Bend radius min (mm):
- 120.000
- Burst pressure (bar):
- 1520
- Burst pressure (psi):
- 22000
- Impulse cycle (cycles):
- 500000
- Inside diameter (inch):
- 0.75
- Inside diameter (mm):
- 19.00
- Outside diameter (inch):
- 1.21
- Outside diameter (mm):
- 30.70
- Package form:
- Bulk
- Qualified hose fittings:
- Reusable
- Size:
- -12
- Working pressure max (bar):
- 380
- Working pressure max (psi):
- 5500
- Working temperature max (C):
- 126
- Working temperature max (F):
- 260.0
- Working temperature min (C):
- -40
- Working temperature min (F):
- -40.0
- Lay line style:
- Ink transfer
