Cross References:
MC5405X20X20, GG310NP2020
- UPC:
- 678146190925
- Part Number:
- GG310-NP20-20
- Angle shape:
- 90 Degree
- End type 1:
- Male 37 degree
- Hex size 1 IN:
- 1.610
- Hex size 1 MM:
- 40.9
- Product material:
- Carbon steel
- End type 2:
- Male pipe BSPT
- Thread sealant:
- No
- Finish plating:
- Dura-Kote
- Drop dimension IN:
- 2.360
- Drop dimension MM:
- 59.9
- Tube outside diameter 1 IN:
- 1.610
- Tube outside diameter 1 MM:
- 40.9
- Tube outside diameter 2 IN:
- 1.690
- Tube outside diameter 2 MM:
- 42.9
- Working temp max C:
- 204
- Working temp max F:
- 400
- Working temp min C:
- -54
- Working temp min F:
- -65
- Thread size 27:
- R 1 1/4
