Cross References:
FJ35091212S
- UPC:
- 678146014672
- Part Number:
- FJ3509-1212S
- Angle shape:
- 90 Degree
- Compatible hose ID IN:
- 0.630
- Compatible hose ID MM:
- 16.002
- Compatible hoses:
- GH134
- Construction Style:
- Crimp
- End size 1:
- -12
- End type 1:
- Female 45 degree swivel
- Hex size 1 IN:
- 1.250
- Hex size 1 MM:
- 31.800
- Hose cut off factor IN:
- 1.780
- Hose cut off factor MM:
- 45.212
- Hose size:
- -12
- Inside diameter IN:
- 0.470
- Inside diameter MM:
- 11.938
- Product material:
- Carbon steel
- A dimension IN:
- 3.360
- A dimension MM:
- 85.400
- Thread size 1:
- 1 1/16-12 UN
- End connection torque:
- 79-92 lb-ft(107-125 Nm)
- Finish plating:
- Dura-Kote
- Drop dimension IN:
- 3.730
- Drop dimension MM:
- 94.70
- Seal material:
- Hydrogenated Nitrile (HNBR)
