Cross References:
06916E676, 06916E-676
- UPC:
- 678146148162
- Part Number:
- FJ3250-1616S
- Angle shape:
- 90 Degree
- Compatible hose ID IN:
- 1.000
- Construction Style:
- Crimp
- End size 1:
- -16
- End type 1:
- Female 37 degree swivel
- Hex size 1 IN:
- 1.496
- Hex size 1 MM:
- 38.000
- Hose cut off factor IN:
- 2.200
- Hose cut off factor MM:
- 55.900
- Inside diameter IN:
- 0.760
- Inside diameter MM:
- 19.300
- Product material:
- Carbon steel
- A dimension IN:
- 3.190
- A dimension MM:
- 80.900
- Thread size 1:
- 1 5/16-12 UN
- Product length in:
- 3.940
- Finish plating:
- Zinc plating
- Product height in:
- 3.670
- Product height mm:
- 93.218
- Product length mm:
- 100.076
- Product width in:
- 1.500
- Product width mm:
- 38.100
- Drop dimension IN:
- 2.390
- Drop dimension MM:
- 60.80
