Cross References:
FJ3012031212S
- UPC:
- 678146012876
- Part Number:
- FJ3012-03-1212S
- Angle shape:
- 90 Degree
- Compatible hose ID IN:
- 0.750
- Construction Style:
- Reusable
- End size 1:
- -12
- End type 1:
- Tube-O female short pilot
- Hex size 1 IN:
- 1.259
- Hex size 1 MM:
- 32.000
- Hose cut off factor IN:
- 3.520
- Hose cut off factor MM:
- 89.400
- Inside diameter IN:
- 0.470
- Inside diameter MM:
- 11.900
- Product material:
- Carbon steel
- A dimension IN:
- 5.100
- A dimension MM:
- 129.500
- Thread size 1:
- 1 1/16-14 UN
- Product length in:
- 5.720
- Finish plating:
- Zinc plating
- Product height in:
- 3.500
- Product height mm:
- 88.900
- Product length mm:
- 145.288
- Product width in:
- 1.250
- Product width mm:
- 31.750
- Drop dimension IN:
- 2.560
- Drop dimension MM:
- 65.00
- Seal material:
- Hydrogenated Nitrile (HNBR)
