Cross References:
FF9083619
- UPC:
- 639789334176
- Part Number:
- FF90836-19
- Series:
- FF90836 Series
- Application:
- High temperature | Low pressure engine or coolant
- Color:
- Red
- Compliances:
- SAE J20
- Proposition 65:
- Cancer and Reproductive Harm
- Conductivity:
- Conductive
- Cover material:
- Silicone
- Reinforcement material:
- Aramid (Kevlar)
- Tube material:
- Silicone
- Abrasion resistance:
- Premium
- Bend radius min (inch):
- 6.500
- Bend radius min (mm):
- 165.100
- Burst pressure (bar):
- 138
- Burst pressure (psi):
- 2000
- Inside diameter (inch):
- 3.50
- Inside diameter (mm):
- 88.90
- Outside diameter (inch):
- 3.88
- Outside diameter (mm):
- 98.55
- Size:
- -19
- Working pressure max (bar):
- 3
- Working pressure max (psi):
- 40
- Working temperature max (C):
- 260
- Working temperature max (F):
- 500.0
- Working temperature min (C):
- -54
- Working temperature min (F):
- -65.0
- Tube wall thickness (inch):
- 0.19
- Tube wall thickness (mm):
- 4.83
- Lay line style:
- Ink jet
- Matr grp for sales restriction:
- Country Excluded Products
