Cross References:
FF9082912
- UPC:
- 639789333827
- Part Number:
- FF90829-12
- Series:
- FF90829 Series
- Color:
- Red
- Compliances:
- SAE J20
- Proposition 65:
- Cancer and Reproductive Harm
- Conductivity:
- Conductive
- Cover material:
- Silicone
- Reinforcement material:
- Aramid (Kevlar)
- Tube material:
- Silicone
- Abrasion resistance:
- Premium
- Bend radius min (inch):
- 6.500
- Bend radius min (mm):
- 165.100
- Burst pressure (bar):
- 138
- Burst pressure (psi):
- 2000
- Inside diameter (inch):
- 0.75
- Inside diameter (mm):
- 19.05
- Outside diameter (inch):
- 1.14
- Outside diameter (mm):
- 28.96
- Size:
- -12
- Working pressure max (bar):
- 3
- Working pressure max (psi):
- 40
- Working temperature max (C):
- 127
- Working temperature max (F):
- 260.0
- Working temperature min (C):
- -48
- Working temperature min (F):
- -54.0
- Tube wall thickness (inch):
- 0.19
- Tube wall thickness (mm):
- 4.83
- Lay line style:
- Ink jet
