Cross References:
FF9080218
- UPC:
- 639789333483
- Part Number:
- FF90802-18
- Series:
- FF90802 Series
- Application:
- Heavy duty coolant | Low pressure engine or coolant
- Color:
- Blue
- Compliances:
- SAE J20 | SAE J20R1 Class A
- Proposition 65:
- Cancer and Reproductive Harm
- Conductivity:
- Conductive
- Cover material:
- Silicone
- Reinforcement material:
- Fabric
- Tube material:
- Silicone
- Abrasion resistance:
- Premium
- Bend radius min (inch):
- 6.500
- Bend radius min (mm):
- 165.100
- Burst pressure (bar):
- 138
- Burst pressure (psi):
- 2000
- Inside diameter (inch):
- 3.00
- Inside diameter (mm):
- 76.20
- Outside diameter (inch):
- 5.00
- Outside diameter (mm):
- 127.00
- Size:
- -18
- Working pressure max (bar):
- 3
- Working pressure max (psi):
- 40
- Working temperature max (C):
- 177
- Working temperature max (F):
- 350.0
- Working temperature min (C):
- -54
- Working temperature min (F):
- -65.0
- Tube wall thickness (inch):
- 0.22
- Tube wall thickness (mm):
- 5.59
- Lay line style:
- Ink jet
