Cross References:
H24308/08E508/08E, H24308
- UPC:
- 678146191199
- Part Number:
- EN-10TW
- Series:
- EN-TW Series
- Application:
- Electronics
- Product height in:
- 0.500
- Product height mm:
- 12.800
- Product width in:
- 0.500
- Product width mm:
- 12.800
- Compliances:
- SAE J1899
- Construction:
- 1 Wire Braid
- Reinforcement material:
- Stainless steel wire
- Tube material:
- PTFE
- Bend radius min (inch):
- 6.500
- Bend radius min (mm):
- 165.000
- Burst pressure (bar):
- 412
- Burst pressure (psi):
- 6000
- Impulse cycle (cycles):
- 150000
- Inside diameter (inch):
- 0.50
- Inside diameter (mm):
- 12.80
- Outside diameter (inch):
- 0.65
- Outside diameter (mm):
- 16.51
- Package form:
- Bulk
- Qualified hose fittings:
- Contact Danfoss for fittings
- Size:
- -10
- Working pressure max (bar):
- 103
- Working pressure max (psi):
- 1500
- Working temperature max (C):
- 236
- Working temperature max (F):
- 457.0
- Working temperature min (C):
- -54
- Working temperature min (F):
- -65.0
