Cross References:
EH22660 (SOLD IN QTY OF 3)
- UPC:
- 639789332738
- Part Number:
- EH22660
- Series:
- EH226 Series
- Application:
- Low pressure engine or coolant
- Color:
- Blue
- Product height in:
- 3.750
- Product height mm:
- 95.200
- Product width in:
- 3.750
- Product width mm:
- 95.200
- Compliances:
- SAE J20R1 Class A
- Proposition 65:
- Cancer and Reproductive Harm
- Conductivity:
- Conductive
- Construction:
- 4 Ply braid
- Cover material:
- Silicone
- Reinforcement material:
- Aramid (Kevlar)
- Tube material:
- Silicone
- Abrasion resistance:
- Standard
- Burst pressure (bar):
- 17
- Burst pressure (psi):
- 249
- Inside diameter (inch):
- 3.75
- Inside diameter (mm):
- 95.20
- Outside diameter (inch):
- 4.12
- Outside diameter (mm):
- 104.65
- Package form:
- Bulk
- Qualified hose fittings:
- Contact Danfoss for fittings
- Size:
- -60
- Working temperature max (C):
- 177
- Working temperature max (F):
- 350.0
- Working temperature min (C):
- -54
- Working temperature min (F):
- -65.0
- Lay line style:
- Ink jet
