Cross References:
24712N612CT, 24712N-612-CT
- UPC:
- 678146138118
- Part Number:
- 4411-12S
- Angle shape:
- Straight
- Compatible hose ID IN:
- 0.750
- Construction Style:
- Reusable
- End size 1:
- -12
- End type 1:
- Female 37 degree swivel
- Hex size 1 IN:
- 1.250
- Hex size 1 MM:
- 31.750
- Hex size 2 IN:
- 1.250
- Hex size 2 MM:
- 31.750
- Hose cut off factor IN:
- 1.970
- Hose cut off factor MM:
- 50.000
- Inside diameter IN:
- 0.500
- Inside diameter MM:
- 12.700
- Product material:
- Carbon steel
- A dimension IN:
- 3.490
- A dimension MM:
- 88.600
- Thread size 1:
- 1 1/16-12 UN
- Product length in:
- 3.490
- Finish plating:
- Dura-Kote
- Product height in:
- 1.250
- Product height mm:
- 31.750
- Product length mm:
- 88.646
- Product width in:
- 1.250
- Product width mm:
- 31.750
- Reusable socket hex MM:
- 31.750
