Cross References:
22662424S, C5216X24X24
- UPC:
- 678146188311
- Part Number:
- 2266-24-24S
- End type 1:
- Male ORB ISO 11926-3
- Hex size 1 IN:
- 2.125
- Hex size 1 MM:
- 54.000
- Hex size 2 IN:
- 2.250
- Hex size 2 MM:
- 57.200
- Product material:
- Carbon steel
- Thread size 1:
- 1 7/8-12 UN
- End type 2:
- Female 37 degree swivel
- Item type:
- Adapter-straight
- Thread sealant:
- No
- Finish plating:
- Dura-Kote
- Tube outside diameter 1 IN:
- 1.500
- Tube outside diameter 1 MM:
- 38.1
- Tube outside diameter 2 IN:
- 1.500
- Tube outside diameter 2 MM:
- 38.1
- Working temp max C:
- 121
- Working temp max F:
- 250
- Working temp min C:
- -40
- Working temp min F:
- -40
- Thread size 27:
- 1 7/8-12 UN
- Working pressure bar:
- 103
- Working pressure psi:
- 1500.00
