Cross References:
22161212S, C3269X12X12, 2216-12-12S
- Part Number:
- 2216-12-12S-BG
- End type 1:
- Female pipe (NPTF)
- Hex size 1 IN:
- 1.313
- Hex size 1 MM:
- 33.400
- Product material:
- Carbon steel
- Item type:
- Adapter-straight
- Thread sealant:
- No
- Finish plating:
- Dura-Kote
- Tube outside diameter 1 IN:
- 0.750
- Tube outside diameter 1 MM:
- 19.1
- Tube outside diameter 2 IN:
- 0.750
- Tube outside diameter 2 MM:
- 19.1
- Working temp max C:
- 121
- Working temp max F:
- 250
- Working temp min C:
- -40
- Working temp min F:
- -40
- Thread size 27:
- 1 1/16-12 UN
- Working pressure bar:
- 241
- Working pressure psi:
- 3500.00
