Cross References:
20661216S, 9315X16X12
- UPC:
- 678146173041
- Part Number:
- 2066-12-16S
- End type 1:
- Female pipe swivel (NPSM)
- Hex size 1 IN:
- 1.250
- Hex size 1 MM:
- 31.800
- Hex size 2 IN:
- 1.500
- Hex size 2 MM:
- 38.100
- Product material:
- Carbon steel
- Item type:
- Adapter-straight
- Thread sealant:
- No
- Finish plating:
- Dura-Kote
- Tube outside diameter 1 IN:
- 0.750
- Tube outside diameter 1 MM:
- 19.1
- Tube outside diameter 2 IN:
- 1.000
- Tube outside diameter 2 MM:
- 25.4
- Working temp max C:
- 121
- Working temp max F:
- 250
- Working temp min C:
- -40
- Working temp min F:
- -40
- Thread size 27:
- 1 5/16-12 UN
- Working pressure bar:
- 172
- Working pressure psi:
- 2500.00
