Cross References:
20310288S, C5706X8, 203102-8-8S
- Part Number:
- 203102-8-8S-BG
- End type 1:
- Female 37 degree swivel
- Hex size 1 IN:
- 0.740
- Hex size 1 MM:
- 18.800
- Hex size 2 IN:
- 0.875
- Hex size 2 MM:
- 22.200
- Product material:
- Carbon steel
- Thread size 1:
- 3/4-16 UNF
- End type 2:
- Male 37 degree
- Item type:
- Adapter-tee
- Thread sealant:
- No
- Finish plating:
- Dura-Kote
- Drop dimension IN:
- 1.250
- Drop dimension MM:
- 31.80
- Tube outside diameter 1 IN:
- 0.390
- Tube outside diameter 1 MM:
- 9.9
- Tube outside diameter 2 IN:
- 0.390
- Tube outside diameter 2 MM:
- 9.9
- End type 3:
- Male 37 degree
- Tube outside diameter 3 IN:
- 0.390
- Tube outside diameter 3 MM:
- 9.9
- Working temp max C:
- 204
- Working temp max F:
- 400
- Working temp min C:
- -54
- Working temp min F:
- -65
- Thread size 27:
- 3/4-16 UNF
- Thread size 3:
- 3/4-16 UNF
