Cross References:
201866S, 9100X6X6, 2018-6-6S
- Part Number:
- 2018-6-6S-BG
- End type 1:
- Male pipe (NPTF)
- Hex size 1 IN:
- 0.690
- Hex size 1 MM:
- 17.500
- Hex size 2 IN:
- 0.690
- Hex size 2 MM:
- 17.500
- Product material:
- Carbon steel
- End type 2:
- Female 37 degree swivel
- Thread sealant:
- No
- Finish plating:
- Dura-Kote
- Tube outside diameter 1 IN:
- 0.380
- Tube outside diameter 1 MM:
- 9.7
- Tube outside diameter 2 IN:
- 0.375
- Tube outside diameter 2 MM:
- 9.5
- Working temp max C:
- 121
- Working temp max F:
- 250
- Working temp min C:
- -40
- Working temp min F:
- -40
- Thread size 27:
- 9/16-18 UNF
- Working pressure bar:
- 345
- Working pressure psi:
- 5000.00
