Cross References:
04Z-664-BG, 04Z664BG, 04Z-664, 04Z664
- UPC:
- 678146126481
- Part Number:
- 1AA4FJB4
- Series:
- 1A/Z Series
- Angle shape:
- 90 Degree
- Compatible hose ID IN:
- 0.250
- Compatible hose ID MM:
- 6.400
- Construction Style:
- Crimp
- End size 1:
- -4
- End type 1:
- Female 37 degree swivel
- Hose cut off factor IN:
- 0.920
- Hose cut off factor MM:
- 23.300
- Hose size:
- -4
- Inside diameter IN:
- 0.1700
- Inside diameter MM:
- 4.2000
- Product material:
- Carbon steel
- A dimension IN:
- 1.790
- A dimension MM:
- 45.400
- Thread size 1:
- 7/16-20 UNF
- End connection torque:
- 11-12 lb-ft(15-16 Nm)
- Product length in:
- 2.170
- Finish plating:
- Zinc plating
- Product height in:
- 1.470
- Product height mm:
- 37.338
- Product length mm:
- 55.118
- Product width in:
- 0.880
- Product width mm:
- 22.352
- Drop dimension IN:
- 0.680
- Drop dimension MM:
- 17.30
