Cross References:
20Z-657, 20Z657
- UPC:
- 678146180636
- Part Number:
- 1AA20FJC20
- Series:
- 1A/Z Series
- Angle shape:
- 90 Degree
- Compatible hose ID IN:
- 1.250
- Compatible hose ID MM:
- 31.800
- Construction Style:
- Crimp
- End size 1:
- -20
- End type 1:
- Female 37 degree swivel
- Hose cut off factor IN:
- 2.520
- Hose cut off factor MM:
- 64.000
- Hose size:
- -20
- Inside diameter IN:
- 1.010
- Inside diameter MM:
- 25.700
- Product material:
- Carbon steel
- A dimension IN:
- 4.070
- A dimension MM:
- 103.500
- Thread size 1:
- 1 5/8-12 UN
- End connection torque:
- 127-133 lb-ft(173-182 Nm)
- Product length in:
- 5.250
- Finish plating:
- Zinc plating
- Product height in:
- 7.370
- Product height mm:
- 187.198
- Product length mm:
- 133.350
- Product width in:
- 2.410
- Product width mm:
- 61.214
- Drop dimension IN:
- 5.530
- Drop dimension MM:
- 140.50
