Cross References:
12Z-516-BG, 12Z516BG, 12Z-516, 12Z516
- UPC:
- 678146126122
- Part Number:
- 1AA16MJ12
- Series:
- 1A/Z Series
- Angle shape:
- Straight
- Compatible hose ID IN:
- 0.750
- Compatible hose ID MM:
- 19.000
- Construction Style:
- Crimp
- End size 1:
- -16
- End type 1:
- Male 37 degree
- Hex size 2 MM:
- 35.000
- Hose cut off factor IN:
- 1.560
- Hose cut off factor MM:
- 39.700
- Hose size:
- -12
- Inside diameter IN:
- 0.610
- Inside diameter MM:
- 15.500
- Product material:
- Carbon steel
- A dimension IN:
- 2.630
- A dimension MM:
- 66.800
- Thread size 1:
- 1 5/16-12 UN
- End connection torque:
- 108-113 lb-ft(148-154 Nm)
- Product length in:
- 2.750
- Finish plating:
- Dura-Kote
- Product height in:
- 1.580
- Product height mm:
- 40.132
- Product length mm:
- 69.850
- Product width in:
- 1.560
- Product width mm:
- 39.624
