Cross References:
16Z-676-BG, 16Z676BG, 16Z-676, 16Z676
- UPC:
- 678146126009
- Part Number:
- 1AA16FJB16
- Series:
- 1A/Z Series
- Angle shape:
- 90 Degree
- Compatible hose ID IN:
- 1.000
- Compatible hose ID MM:
- 25.400
- Construction Style:
- Crimp
- End size 1:
- -16
- End type 1:
- Split flange code 61
- Hose cut off factor IN:
- 2.870
- Hose cut off factor MM:
- 72.900
- Hose size:
- -16
- Inside diameter IN:
- 0.810
- Inside diameter MM:
- 20.600
- Product material:
- Carbon steel
- A dimension IN:
- 4.380
- A dimension MM:
- 111.300
- Thread size 1:
- 1 5/16-12 UN
- Product length in:
- 5.130
- Finish plating:
- Zinc plating
- Product height in:
- 3.960
- Product height mm:
- 100.584
- Product length mm:
- 130.302
- Product width in:
- 1.940
- Product width mm:
- 49.276
- Drop dimension IN:
- 2
- Drop dimension MM:
- 61
