Cross References:
32ZG54, 32Z-G54
- UPC:
- 678146124098
- Part Number:
- 1A24FLA32
- Series:
- 1A/Z Series
- Angle shape:
- 45 Degree
- Compatible hose ID IN:
- 2.000
- Compatible hose ID MM:
- 50.800
- Construction Style:
- Crimp
- End size 1:
- -24
- End type 1:
- Split flange code 61
- Hose cut off factor IN:
- 4.210
- Hose cut off factor MM:
- 107.000
- Hose size:
- -32
- Inside diameter IN:
- 1.260
- Inside diameter MM:
- 32.000
- Product material:
- Carbon steel
- A dimension IN:
- 6.030
- A dimension MM:
- 153.200
- Product length in:
- 7.450
- Finish plating:
- Dura-Kote
- Product height in:
- 4.200
- Product height mm:
- 106.680
- Product length mm:
- 189.230
- Product width in:
- 3.220
- Product width mm:
- 81.788
- Drop dimension IN:
- 1
- Drop dimension MM:
- 36
