Cross References:
16ZH53, 16Z-H53
- UPC:
- 678146123879
- Part Number:
- 1A16FLG16
- Series:
- 1A/Z Series
- Angle shape:
- 60 Degree
- Compatible hose ID IN:
- 1.000
- Compatible hose ID MM:
- 25.400
- Construction Style:
- Crimp
- End size 1:
- -16
- End type 1:
- Split flange code 61
- Hose cut off factor IN:
- 3.890
- Hose cut off factor MM:
- 98.700
- Hose size:
- -16
- Inside diameter IN:
- 0.780
- Inside diameter MM:
- 19.900
- Product material:
- Carbon steel
- A dimension IN:
- 5.220
- A dimension MM:
- 132.500
- End connection torque:
- 32-35 lb-ft(43-47 Nm)
- Product length in:
- 6.970
- Finish plating:
- Dura-Kote
- Product height in:
- 4.230
- Product height mm:
- 107.442
- Product length mm:
- 177.038
- Product width in:
- 1.940
- Product width mm:
- 49.276
- Drop dimension IN:
- 1.510
- Drop dimension MM:
- 38.30
