Cross References:
08Z15C, 08Z-15C
- UPC:
- 678146123459
- Part Number:
- 1A12DL8
- Series:
- 1A/Z Series
- Angle shape:
- Straight
- Compatible hose ID IN:
- 0.500
- Compatible hose ID MM:
- 12.700
- Compatible tube OD IN:
- 0.75
- Compatible tube OD MM:
- 19.050
- Construction Style:
- Crimp
- End size 1:
- -12
- End type 1:
- 24 deg. DKO swivel light duty
- Hex size 1 IN:
- 1.060
- Hex size 1 MM:
- 26.924
- Hose cut off factor IN:
- 1.130
- Hose cut off factor MM:
- 28.600
- Hose size:
- -8
- Inside diameter IN:
- 0.380
- Inside diameter MM:
- 9.600
- Product material:
- Carbon steel
- Tube OD 1 IN:
- 0.750
- Tube OD 1 MM:
- 19.050
- A dimension IN:
- 2.300
- A dimension MM:
- 58.300
- Thread size 1:
- M22x1.5
- End connection torque:
- 43-48 lb-ft(59-64 Nm)
- Product length in:
- 2.300
- Finish plating:
- Dura-Kote
- Product height in:
- 1.220
- Product height mm:
- 30.988
- Product length mm:
- 58.420
- Product width in:
- 1.220
- Product width mm:
- 30.988
- Seal material:
- Nitrile (NBR)
