Cross References:
08Z15A, 08Z-15A
- UPC:
- 678146123442
- Part Number:
- 1A12DK8
- Series:
- 1A/Z Series
- Angle shape:
- Straight
- Compatible hose ID IN:
- 0.500
- Compatible hose ID MM:
- 12.700
- Compatible tube OD IN:
- 0.75
- Compatible tube OD MM:
- 19.050
- Construction Style:
- Crimp
- End size 1:
- -12
- End type 1:
- 24 deg. tube port light duty
- Hex size 1 IN:
- 0.940
- Hex size 1 MM:
- 23.900
- Hex size 2 MM:
- 24.000
- Hose cut off factor IN:
- 1.040
- Hose cut off factor MM:
- 26.300
- Hose size:
- -8
- Inside diameter IN:
- 0.380
- Inside diameter MM:
- 9.600
- Product material:
- Carbon steel
- Tube OD 1 IN:
- 0.750
- Tube OD 1 MM:
- 19.050
- A dimension IN:
- 2.200
- A dimension MM:
- 56.000
- Thread size 1:
- M22x1.5
- Product length in:
- 2.200
- Finish plating:
- Dura-Kote
- Product height in:
- 1.220
- Product height mm:
- 30.988
- Product length mm:
- 55.880
- Product width in:
- 1.220
- Product width mm:
- 30.988
