Cross References:
06Z14E, 06Z-14E
- UPC:
- 678146123299
- Part Number:
- 1A10DSA6
- Series:
- 1A/Z Series
- Angle shape:
- 45 Degree
- Compatible hose ID IN:
- 0.380
- Compatible hose ID MM:
- 9.500
- Compatible tube OD IN:
- 0.63
- Compatible tube OD MM:
- 15.875
- Construction Style:
- Crimp
- End size 1:
- -10
- End type 1:
- 24 deg. DKO swivel heavy duty
- Hex size 1 IN:
- 1.060
- Hex size 1 MM:
- 26.924
- Hose cut off factor IN:
- 1.710
- Hose cut off factor MM:
- 43.500
- Hose size:
- -6
- Inside diameter IN:
- 0.260
- Inside diameter MM:
- 6.700
- Product material:
- Carbon steel
- Tube OD 1 IN:
- 0.625
- Tube OD 1 MM:
- 15.875
- A dimension IN:
- 2.710
- A dimension MM:
- 68.800
- Thread size 1:
- M22x1.5
- End connection torque:
- 52-66 lb-ft(70-90 Nm)
- Product length in:
- 3.240
- Finish plating:
- Dura-Kote
- Product height in:
- 1.850
- Product height mm:
- 46.990
- Product length mm:
- 82.296
- Product width in:
- 1.070
- Product width mm:
- 27.178
- Drop dimension IN:
- 0.790
- Drop dimension MM:
- 20.00
- Seal material:
- Nitrile (NBR)
- Proposition 65:
- Cancer and Reproductive Harm
