Cross References:
1.60E+117
- Part Number:
- 16E-116
- Series:
- E Series
- Angle shape:
- Straight
- Compatible hose ID IN:
- 1.000
- Compatible hose ID MM:
- 25.400
- Compatible hoses:
- H009 | H209 | H243 | H265 | H275 | H277 | H285 | H435 | H436
- Compatible tube OD IN:
- 1.00
- Compatible tube OD MM:
- 25.400
- Construction Style:
- Crimp
- End size 1:
- -16
- End type 1:
- Male pipe (NPTF)
- Hex size 1 IN:
- 1.380
- Hex size 1 MM:
- 35.100
- Hex size 2 IN:
- 1.375
- Hex size 2 MM:
- 34.925
- Hose cut off factor IN:
- 1.610
- Hose cut off factor MM:
- 40.894
- Hose size:
- -16
- Inside diameter IN:
- 0.8400
- Inside diameter MM:
- 21.3360
- Product material:
- Carbon steel
- Tube OD 1 IN:
- 1.000
- Tube OD 1 MM:
- 25.400
- A dimension IN:
- 3.563
- A dimension MM:
- 74.930
- Thread size 1:
- 1-11 1/2 NPTF
- Product length in:
- 3.000
- Finish plating:
- Zinc plating
- Product height in:
- 1.590
- Product height mm:
- 40.386
- Product length mm:
- 76.200
- Product width in:
- 1.500
- Product width mm:
- 38.100
