Cross References:
05E505
- UPC:
- 725975771235
- Part Number:
- 05E-505
- Series:
- E Series
- Angle shape:
- Straight
- Compatible hose ID IN:
- 0.310
- Compatible hose ID MM:
- 7.900
- Construction Style:
- Crimp
- End size 1:
- -5
- End type 1:
- Male 37 degree
- Hex size 2 IN:
- 0.563
- Hex size 2 MM:
- 14.000
- Hose cut off factor IN:
- 0.930
- Hose cut off factor MM:
- 23.620
- Hose size:
- -5
- Inside diameter IN:
- 0.197
- Inside diameter MM:
- 5.000
- Product material:
- Carbon steel
- A dimension IN:
- 1.780
- A dimension MM:
- 45.210
- Thread size 1:
- 1/2-20 UNF
- End connection torque:
- 14-15 lb-ft(19-21 Nm)
- Finish plating:
- Zinc plating
