The Monroe® Gas-Magnum® Rear Suspension Shock Absorber is designed for midsize and full-size trucks, providing firm control without a harsh ride. With up to twice the fluid capacity of standard 1-in. bore shocks, Gas-Magnum shocks work more efficiently with less effort.

A durable, economical replacement backed by Monroe's Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee, the Gas-Magnum restores dependable rear suspension performance for your classic Chevrolet Suburban.

• Designed for Trucks and Vans: Full-displaced valving on compression cycles delivers controlled ride and handling.
• Built to Last: Heavy-duty nitrocarburized rod (non-dust shield units only) and sintered iron piston enhance durability; self-lubricating fluid seal reduces piston rod wear.
• Consistent Ride: OE all-weather fluid with special modifiers handles extreme temperatures and ensures smooth rod reaction.
• Improves Performance: Nitrogen gas-charge maintains tire-to-road contact by reducing aeration and shock fade.
• Longer Service Life: Larger bore and bigger 2-in. reserve tube hold more oil for greater capacity and long-term performance.
• Buy with Confidence: Backed by Monroe's Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee.

Common Fits: Chevrolet C10 Suburban (1967-1972). Rear position.

---

Cross References:
Chevrolet: 22011979, Chevrolet: 22011984, Chevrolet: 3187843, Chevrolet: 3187844, Chevrolet: 4993562, GMC: 22011979, GMC: 22011984, GMC: 3187843, GMC: 3187844, GMC: 4993562, FCS: 342780, FCS: 342781, KYB: 344067, KYB: 344072, ACDelco: 520145, ACDelco: 52016, ACDelco: 530129, Gabriel: 58347, Gabriel: 58355, Gabriel: 58908, Monroe Shocks & Struts: 6061, Monroe Shocks & Struts: 6072, NAPA Shocks: 76944, KYB: 344075, KYB: 344085, KYB: 565031, KYB: 565037, KYB: 565039, KYB: KG5408, KYB: KG5416, KYB: KG5419, KYB: KG5430, KYB: KG5477, ACDelco: 6061, NAPA Proformer: SH82003, MasterPro Shocks and Struts: GM133, Monroe Shocks & Struts: 33074, Monroe Shocks & Struts: 37040, Monroe Shocks & Struts: 210171, Sensen: 12130188, F34944

---

UPC:

048598469359

Mfr Part Number:

34944

Country of origin (CO):

CN

Color:

Yellow

Compressed Length:

11.75 (unece.unit.INH)

Cylinder Color:

Yellow

Cylinder Finish:

Painted

Dust Shield Included:

Yes

Dust Shield Material:

Metal

Extended Length:

18.375 (unece.unit.INH)

Gas Charged:

Yes

Grade Type:

Premium

Hydraulic Lockout:

No

Includes Bump Stop:

No

Internal Rebound Bumper:

No

Lower Mount Code:

LS37

Lower Mount Type:

Loop (Eyelet) Bushing and Sleeve

Mounting Hardware Included:

Yes

Shock Absorber Body End Measuring Point:

Center of Loop

Shock Absorber Rod End Measuring Point:

Center of Loop

Travel Length:

6.625 (unece.unit.INH)

Upper Mount Code:

LS37

Lower Mount Code48:

LS37

Upper Mount Code74:

LS37

Lower Mount Type49:

Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 1.3/8" Sleeve OAL

Parts Pack(s):

P00816

Upper Mount Type75:

Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 34.93MM Sleeve OAL
