Hub Unit Bearing Assemblies: Preset, Pre-Greased And Pre-Sealed

Application: Lexus (06-05)

---

Cross References:
BECK-ARNLEY: 051-6249, CENTRIC: 407.44002, FEDERAL-MOGUL: 513163, RAYBESTOS: 713163, SKF: BR930293, TOYOTA: 4355050010, TOYOTA: 4355050011

UPC:

053893977294

Mfr Part Number:

HA593550

ABS Type - Tone Ring / Sensor / Encoder (T/S/E):

S

ABS/Non-ABS (Y/N):

Y

Bearing Type:

Ball

Bolt Circle Diameter B (in.):

4.5

Bolt Circle Diameter B (mm):

114.3

Bolt Circle Diameter H (in.):

4.409

Bolt Circle Diameter H (mm):

112

Bolt Quantity I:

(4)

Bolt Size I (in.):

M12x1.25

Brake Pilot Dia E (in.):

2.44094488188976

Brake Pilot Dia E (mm):

62

Driven - Non Driven (D / N):

N

Flange (#):

2

Flange Diameter A (in.):

5.51181102362205

Flange Diameter A (mm):

140

Flange Offset F (in.):

2.16535433070866

Flange Offset F (mm):

55

Flange Shape J:

Modified

Gen Type (1/2/3):

3

Hub Pilot Dia G (in.):

2.91338582677165

Hub Pilot Dia G (mm):

74

Roll Form (Y):

N

Wheel Pilot Dia D (mm):

60

Wheel Stud Qty:

5

Wheel Stud Size (in.):

M12x1.5

Whl Studs (Y/N):

Y
