Hub Unit Bearing Assemblies: Preset, Pre-Greased And Pre-Sealed

Application: Chevrolet (07-05); Pontiac (07-05)

---

Cross References:
CENTRIC: 400.62008, DELCO / AC-DELCO: FW323, FEDERAL-MOGUL: 513215, GENERAL MOTORS CORP.: 22706425, RAYBESTOS: 713215, SKF: BR930314

UPC:

053893983202

Mfr Part Number:

HA590071

Bearing Type:

Ball

Bolt Circle Diameter B (in.):

4.33070866141732

Bolt Circle Diameter B (mm):

110

Bolt Circle Diameter H (in.):

4.48818897637795

Bolt Circle Diameter H (mm):

114

Bolt Quantity I:

(3)

Bolt Size I (in.):

M12x1.75

Brake Pilot Dia E (in.):

2.57665354330709

Brake Pilot Dia E (mm):

65.447

Driven - Non Driven (D / N):

D

Flange (#):

2

Flange Diameter A (in.):

5.39370078740158

Flange Diameter A (mm):

137

Flange Offset F (in.):

1.53543307086614

Flange Offset F (mm):

39

Flange Shape J:

Modified

Gen Type (1/2/3):

3

Hub Pilot Dia G (in.):

3.54330708661417

Hub Pilot Dia G (mm):

90

Roll Form (Y):

Y

Spline Quantity:

30

Wheel Pilot Dia D (mm):

64.967

Wheel Stud Qty:

5

Wheel Stud Size (in.):

M12x1.5

Whl Studs (Y/N):

Y
