Hub Unit Bearing Assemblies: Preset, Pre-Greased And Pre-Sealed

Application: Chevrolet (96-84)

---

Cross References:
CENTRIC: 400.62004, DELCO / AC-DELCO: 2045, FAG BEARING: RW920, FEDERAL-MOGUL: 513020, RAYBESTOS: 713020, SKF: BR930024

UPC:

053893836423

Mfr Part Number:

513020

Bearing Type:

Ball

Bolt Circle Diameter B (in.):

4.75

Bolt Circle Diameter B (mm):

120.65

Bolt Circle Diameter H (in.):

4.75

Bolt Circle Diameter H (mm):

120.65

Bolt Quantity I:

(3)

Bolt Size I (in.):

M12x1.75

Brake Pilot Dia E (in.):

2.77952755905512

Brake Pilot Dia E (mm):

70.6

Driven - Non Driven (D / N):

D

Flange (#):

2

Flange Diameter A (in.):

5.594

Flange Diameter A (mm):

142.1

Flange Offset F (in.):

1.86141732283465

Flange Offset F (mm):

47.28

Flange Shape J:

Modified

Gen Type (1/2/3):

2

Hub Pilot Dia G (in.):

3.621

Hub Pilot Dia G (mm):

91.98

Roll Form (Y):

N

Spline Quantity:

27

Wheel Pilot Dia D (mm):

70.1

Wheel Stud Qty:

5

Wheel Stud Size (in.):

M12x1.5

Whl Studs (Y/N):

Y
